Product specifications

• Printer Type Serial Impact Dot Matrix Printer
• Functions Mono Single Function Printer: 136 Column
• Printing Method / Technology 9 Pin Impact Dot Matrix
• Printhead Impact Dot Matrix Printhead
• Printhead Configuration Pin Configuration: 9 Pin x2
• Print Direction Bi-direction with logic seeking
• Column Capacity (cpl) 136 columns (10 cpi)
• Control Code ESC/P2 and IBM PPDS
• Print Font Bitmap Fonts: Draft: 10 cpi, 12 cpi, 15 cpi; Epson Roman / Epson Sans Serif: 10, 12, 15 cpi, Proportional
  Scalable Fonts: Epson Roman / Epson Sans Serif
• Character Set 13 character tables: 1 Italic and 12 graphical character tables: Italic table, PC437 (US, StandardEurope), PC850 (Multilingual), PC860 (Portuguese), PC861 (Icelandic), PC865 (Nordic), PC863 (Canadian-French), Abicomp, BRASCII, Roman 8, ISO Latin 1, PC858, ISO 8859-15
• Barcode / 2D Code EAN-13, EAN-8, Interleaved 2 of 5, UPC-A, UPC-E, Code 39, Code 128, PostNet
• Print Speed 496 cps - Ultra Speed Draft (10 cpi)
  496 cps - High Speed Draft (10 cpi)
  372 cps - Draft (10 cpi)
  93 cps - NLQ (10 cpi)
  Note: Print speed varies depending on system configuration, print mode, document complexity, software, interface, page coverage, paper type, connectivity, etc.
• Ink or Toner Save Mode Yes (Draft Mode)
• Automatic 2-sided printing n/a
• Paper Feed Method Tractor, Friction Insertion
• Paper Trays / Paper Path Manual Insertion (Front or Rear in, Top out)
  Push tractor (Front or rear in, Top out)
  Pull tractor (Front, rear or bottom in, Top out)
• Paper / Media Type Multi-part Forms, Cut Sheet, Continuous Paper, Envelopes, Labels, Roll Paper
• Paper Weight / Thickness Cut Sheet: 0.065 - 0.14mm
  Continuous Paper: 0.065 - 0.39 mm
  Envelopes: 0.16 - 0.52 mm
  Roll Paper: 0.07 - 0.09 mm
• Paper Size Cut Sheet: 100 - 420 mm (Length), 100 - 420 mm (Width)
  Continuous Paper: 101.6 - 558.8 mm (Length), 101.6 - 406.4 mm (Width)
  Envelopes: No.6, No.10
  Roll Paper: 216 mm (Width)
• Maximum Paper Size 420.0 x 558.8 mm (16.5 in x 22.0 in)
• Print Copies 1 Original + 4 Copies
• Line Spacing 4.23 mm (1/6”) or programmable in increments of 0.059mm (1/432”)
• Data Buffer 128 KB
• Interface USB 2.0 Hi-Speed
  LPT (Bi-directional Parallel) (IEEE-1284 nibble mode supported)
• Control Panel Functions 6 switches and 10 LEDs
• Operating System Compatibility Microsoft® Windows® XP / Vista / 7 / 8 / 10
• Driver / Utility / Software Epson Status Monitor 3, Epson Printer Setting
• Accessories (Optional) Pull Tractor Unit (C12C933791), Single Bin Cut Sheet Feeder (C12C806392)
• PrintHead / Mechanism Life 200 million strokes / wire
• Mean Time Between Failure (MTBF) 15,000 Power On Hours (POH) (25% Duty)
• Mean Print Volume Between Failure (MVBF) 30 million lines (except printhead)
• Power Supply Internal
• Rated Voltage AC 220 - 240 V
• Rated Frequency 50 Hz - 60 Hz
• Power Consumption 54 W (Operating), 0.5 W (Sleep), 0.1 W (Power Off)
• Humidity Range 10 - 80% RH (Operating)
• Temperature Range 5 - 35°C (Operating)
• Noise Level Printing 56 dB(A) (ISO 7779 pattern)
• Consumables in the box Standard Fabric Ribbon Cartridge (Black)
  Ribbon Life: Approx. 12 million Characters
• Orderable Consumables Ribbon Cartridge (Black) - (C13S015584)
• Warranty 2 Year Onsite Service Warranty.
  (Epson’s warranty includes coverage of printhead.)
• Dimensions (LxWxH) 375 x 612 x 176.5 mm
• Net Weight 9.4 Kg
• Disclaimer » Information correct at time of publishing June 2019.
  » We made every effort at the time of publication to ensure the accuracy of the information provided herein, product specifications, colours, configurations, prices, options, accessories may vary from those shown and are all subject to change by the manufacturer without notice. Errors and Omissions Excepted.
